Main Description
These red nylon insulated ring terminals provide a strong and dependable connection for a wide range of electrical wiring applications. The ring design allows the terminal to be securely fastened to studs or screws, making it ideal for automotive, marine, industrial and general electrical installations.
Manufactured from brass with a tin-plated finish, these terminals offer excellent conductivity and corrosion resistance. The nylon insulation provides additional protection and durability, while the flared barrel design allows for quick and easy wire insertion during installation.
Suitable for smaller-gauge wiring, these terminals are ideal for professional wiring, repairs and maintenance work.
Technical Data
- Type: Insulated ring terminal
- Colour: Red
- Conductor material: Brass
- Plating: Tin
- Insulation material: Nylon
- Wire range: 0.5 – 1.5 mm²
- Voltage rating: 600V max.
- Operating temperature: -40°C to +105°C
- Dimensions:
- Width (W): 10 mm
- Length (L): 38 mm
